1/4 Inch Stainless Steel Fog Cannon Mist Spray Nozzle
Customization:
- Customized logo(Min. Order: 50 Pieces)
- Customized packaging(Min. Order: 5000 Pieces)
- Graphic customization(Min. Order: 5000 Pieces)
Design Features:
Fine atomizing mist nozzle utilizes the fluid pressure to produce the extremely fine particle, and the pray pattern is a uniform hollow cone, which can make the spray like fogs. All the parts are precisely composed. The inlay of orifice, the taper core and the strainer are easy to dismantled for excaming and washing. All the above nozzles have strainers.
Common Applications:
1. Moistening in air control chamber
2. Cooling for gas and metal
3. Liquid medicine spraying
4. Humidity conditioning
5. Evaporative cooling
Specification
| Product name | AAZ Fine Misting Nozzle |
| Material | 303SS, 316SS, Brass |
| Thread Size | AAZ 1/4” |
| Thread Type | BSPT, NPT, Male, Female |
| Working Pressure | 2 Bar — 70Bar |
| Spray Angle | 35°—165° |
| Flow Rate | 4.3L/h — 495L/h |
| Droplet Size | 80-100 um |
| Application | 1. Moistening in air control chamber 2. Cooling for gas and metal 3. Liquid medicine spraying 4. Humidity conditioning 5. Evaporative cooling |
| Brand | Spray Nozzles Online |
Product Overview :
Warranty: Unavailable
Applicable Industries: Hotels, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Home Use, Retail, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company, Other
Video outgoing-inspection: Provided
Machinery Test Report: Provided
Marketing Type: New Product 2020
Brand Name: Spray Nozzles Online
Condition: New
Product name: AAZ Misting Spray Nozzle
Model: AAZ
Thread Size: 1/4
Thread Type: BSPT, NPT
Spray Pattern: Misting Pattern
Spray Angle: 35° — 170°
Flow Rate: 4.3L/h to 495L/h
Material: 303SS, 316SS, Brass
Working Pressure: 2 Bar — 70Bar
Brand: Spray Nozzles Online
After Warranty Service: No service
Local Service Location: India
Supply Ability
Supply Ability 500 Piece/Pieces per Day
-
-
-
-
